• Topper

  • Optional LED Topper Sign
  • Can accept custom inserts

  Integrated Illuminated Sign

  • High Visiblility LED Sign
  • Attract Customers

  LCD Screen

  • 10.2 inch wide 32-bit color
  • Backlit TFT LCD panel
  • 1280x800 Resolution
  • 12 inch touch-screen (Optional)
  • Customizable Ad Screens

  Printer

  • 56mm (2" standard)
  • 80mm (3" optional)
  • Graphics Capable with 3"

  PIN Entry Device

  • 16-key alphanumeric keypad
  • PCI Certified
  • Triple-DES (TDES) compliant EPP

  Communication

  • 56Kb Internal Model
  • TCP/IP Ethernet - SSL

  CPU

  • Cortex-A8 CPU (800MHz)
  • DDR2 256MB SRAM memory
  • 512MB Flash Memory
  • Windows CE 6.0

  Card Reader

  • DIP Type card reader
  • EMV Optional

  ADA

  • Voice Guidance
  • Lighted Transaction Guidance
  • Accessible Keypad Layout

  Security

  • UL291 Business Hours Vault
  • Electronic Locks
  • A series Lock
  • Kaba MasCencon Locks

  Cash Dispenser

  • 1000 Note Removable Cassette (SCDU)
  • Up to 4 x 2000 Note Removable Cassette (HCDU)
  Dimensions
• Height = 63”
• Width = 27”
• Depth = 19”
• Weight = 175 lbs (With SCDU cash dispenser and packing)

Power Requirements

• 110/220 VAC ±10%, 50/60 Hz, 145 Watts

Temperature Requirements

• In storage: 32°F - 104°F (0°C ~ 49°C)
• While operating: 45°F - 95°F (5°C ~ 35°C)

Allowable Humidity

• In storage : 10% < RH < 90%, non-condensed
• While operating : 15% < RH < 85%, non-condensed
